Tuesday, 31 December 2019

Look back on the decade

A lot of people have done these on Twitter, so thought I'd do one too. However, instead of doing it on Twitter, I thought I needed to reawaken my blog after it had a quiet 2019. I'll explain why when we get there...

2010: I finished my degree: MSci in Palaeontology and Evolution from the University of Bristol. I received a 2(1). Slightly disappointing for me as I was always a super high achiever through school, but I didn't do as much as I needed to to achieve a 1st so cannot complain. However, my project on spinosaur snouts and their biomechanics would lead me down my current career path. I also was accepted to do, and started, a PhD at the University of Bristol where I would transition from spinosaurs to ornithomimosaurs.

2010 was also the first time I went on a dig, joining a very experienced crew from the Museum of the Rockies. I helped dig up the skull of "Yoshi's Trike" with the remainder of the skeleton being dug up the next year when I wasn't there.

2011: I spent a large chunk of my year playing with ostrich heads for my PhD research. I submitted my thesis from my masters for the first time, and got major revisions for the first time. I visited Canada to go on my second dig, this time with University of Alberta where we spent a large chunk of the time digging up a Daspletosaurus. Following the trip I got to visit the collections in the Royal Tyrrell Museum and the Royal Ontario Museum which were incredible. I also attended my first conference, SVP in Las Vegas which I thought was a lot of fun, but I know the feeling was not shared by all.


2012: I spent a lot of the year working on CT scans of ornithomimosaurs, including a couple I had seen in Canada. No digs this year. I attended my first ProgPal conference in Cambridge, and was off to China and Mongolia to have a look at the collections there. After the summer I went to SVP in Raleigh, NC. I also resubmitted my spinosaur paper and had the same result, with more major revisions to make. I supervised masters level student projects for the first time.

2013: I started the year with my first SICB conference, in San Francisco. I then spent the year finishing the research and writing up my PhD, with a couple more conferences breaking up the year - ICVM in Barcelona, and my third SVP conference, this time in Los Angeles. I submitted my PhD on Thursday 12 December. I had originally planned to submit on Friday the 13th, because why wouldn't you? As it happened, I finished the day early and used the extra day to tidy and pack because I was moving to London in the new year to start a job at UCL and RVC. I finally published my Masters research!

2014: I started my first postdoc in February having taken a month and a half off work to recuperate from the PhD writeup. It was needed as two people independently said I "looked well". A sign that sometimes a break is good. The postdoc was on the evolution of felids, particularly their vertebral morphology and muscles and how that affected their biomehanics. A lot of the year involved looking at the evolution of body size within the group, but I did start dissecting various felids. I would finish 2014 in India in the field in Tamil Nadu with Anjali and her group. I attended SVP again (Berlin), and competed in the Romer Prize session (I did not win), and started my blog! Across the year I published 2 papers, and had more in review.


2015: I started the year in the field of India. On the return to England it was lots of dissections to try to complete our study of cat muscles. I would go to SVP in Dallas, which turned out to be the last for a while with a new job in 2016. I finally got back into the field, this time to Argentina. I had my best year for publishing to date with 4 accepted.


2016: I spent the first part of the year reconstructing fossil felids, initially with brains (picked up by a summer student and accepted for publication), and then muscles on Panthera atrox. I went on to build SIMM models of modern felids (domestic cat and lion), but sadly these still remain on the long to do list! We had a student from the vet college also get permission to do work with various zoological collections so we measured forces and join angles in several living cat species. I was able to get back to Argentina again with Anjali and co. and I attended my second ICVM, this time in Bethesda (near Washington DC). In August I was expecting to be unemployed but was able to secure a short technician post at RVC which allowed me some time to complete work. I was also lucky enough to be hired on to start my next postdoc on the DawnDinos project. 4 more papers accepted.


2017: The early part of the year was spent working on CT scans of Mussaurus whilst we awaited tinamous and crocodiles for the project. When the crocodiles eventually arrived we carried out the surgical procedures and experimental protocols collecting lots of data. However, 2017 was a year where I first ran into my mental health problems caused through burnout. Whilst I will never be cured, it is at least now managed. I published 2 more papers.

2018: The year started with SICB as it returned San Francisco where I talked about Mussaurus. Experiments continued, and thankfully concluded. I was able to escape back into the field, again to Argentina, but this time down in Patagonia. There was a lot of work analysing the experimental EMG data we collected, and incorporating some from historical data collection. I returned to SVP (in Albuquerque) after a few years away and went on my first field trip at an SVP conference into a fun little quarry. No papers this year...

2019: This year has been an unusual year. After a long publishing hiatus (for me at least), I was able to get a couple of papers out, including the Mussaurus paper which got picked up by some press which was an interesting experience. I was also invited onto the editorial board of PLOS One so now am handling papers! Besides that, there was a lot of data processing as part of the postdoc. I got to go to ICVM in Prague in July, but by the summer it was known by lots that I would be leaving the RVC. I have been looking for permanent jobs for a long time and having interviewed and come close to a couple of jobs, I was offered an anatomy assistant lectureship at the Hull York Medical School (University of York campus). Whilst not permanent, it provides me a 2 year teaching opportunity with a lot of lecturing, particularly to medical students (I'll write more about the job search over the last few years in a blog in the new year). In August I finished at the RVC, and left London (after 5 years), and moved to York. It has been a busy learning curve, but it has been fun and I am enjoying the teaching. Next term will be busier, but after this year I should have completed all the prep to make my second year of teaching much easier.

That's my decade in review. No doubt I have missed lots of things or at least glanced over them, such as having some very good students. My first Masters students having finished their PhDs and I am very proud to have been even a small influence in their careers to date.

I wish everyone a happy 2020, and a fruitful decade whatever it may bring.

Saturday, 25 May 2019

3D printing a crocodile

I have to say I was surprised how enthused everyone was for the 3D printed crocodile. It was the most interacted tweet I have ever done, and as promised I am ensuring all of the files are available so if people are keen they can do their own:


All files will print on a print bed that is 20x20cm, and are all scaled to the same size. However do check and scale up or down by 10 if required.

Forelimb (L - R)
Posteriormost Caudal vertebrae
Method
So for anyone wondering how I put it together, it was fairly straight forward, albeit time consuming. If you don't have a set of 3D files (in this case ours were generated from CT scans and segmented in Mimics), there are an abundance of online 3D scans now in places like Morphosource, or phenome10k.org and even thingiverse (the Makerbot repository where I've uploaded my bits), but I strongly encourage you to check the specifics with regards to the use of their scans and to only print things you are allowed to.

The next steps involve tidying up your meshes, e.g. decimation of your mesh to make it smaller/easier to use, and remeshing to standardise triangle sizes etc. I recommend Meshlab for a lot of this as it is free. Google is also full of how-tos, but I am happy help. Feel free to reach out here or Twitter.

I then separated the sections I wanted using the select tool and deleting the unwanted bits. This could, and should, be done in segmentation if you have the scans, but I have to admit I wasn't sure how I was going to separate things when I first started. You will also likely get 3D models online that need separating, so not bad practice. In the case of the vertebral column where I separated the different regions, holes were created in the mesh (where the vertebrae were connected as a single unit). I fixed these in Blender (again a free download) by selecting the nodes in Edit Mode and making new faces to fill the holes.

For sections I wanted to fuse together I created a cylinder where an end was in a bone of interest.
Right lower leg and foot with cylinders shown between all the bones.
In the case of the osteoderms, I created a scaffold of cylinders that would sit on the vertebrae, and then vertical cylinders to attach to the osteoderms:

Scaffold for the dorsal osteoderms (from shoulders to pelvis) in the foreground, with complete scaffold with fused osteoderms for pelvis in the background.
Originally, I used the Boolean tool in Blender to union join the various parts and the cylinder:


but I found that this was not necessary for our printer/software (printing done on a Ultimaker 3 extended, Cura software) so later parts just had cylinders and bones saved together as a single obj. Your experiences may vary!

I printed all of the model on the Ultimaker 3 as I said above, using a normal 0.15mm layer thickness, automated support in the zig-zag shape with chunks enabled, and either a raft or brim support using generic PLA (2.85mm thickness) purchased from Amazon. We have the option of using 2 materials, and this probably would have been better to print using soluble material (PVA) for the support as it took a long time to manually remove the supports but as this was a test it was cheaper and far quicker to print just using the one material. It is not a perfect method and some of the smallest bits have really thin supports and broke during separation so some superglue was used to reattach them. I suspect something like a soldering iron (anything that gets up to 200C) to quickly remelt the ends could also work but please use caution and common sense!

Because our model was printed in chunks (due to the 20x20cm plate), but the original animal was obviously fully connected I created some supports for the dorsal vertebrae to get everything to the appropriate height and to ensure a realistic look. This was achieved by creating a cylinder or cube in Blender, and scaling it to be about 1.5 times wider than a single vertebrae, and a bit longer than 2 vertebrae. I then boolean subtracted the vertebrae from the cylinder, creating a vertebrae cradle. The concave surfaces of the cradle (where there are overhangs) were deleted in the edit mode (and new faces were made to fill the holes) so that the print could be slotted into the cradles.
Vertebral cradle
A disc at the horizontal level of the sternum was created and then a cylinder (other shapes available) created to connect the two (same method as for connecting bones). For the support of the vertebrae over the sternum I created a hollow where the sternum was so that the support would sit flush on the ground with the sternum passing between it by boolean subtracting a slightly enlarged sternum from the underside of the disc (the same procedure as for the vertebrae and cylinder except now for the disc).
In place in the model showing off the front support also has a gap for the sternum.
For our printer there is less support created if you change the shape up to whatever the minimum overhang angle (45-60 degrees depending on the machine) so other shapes may be better for print times/reducing support structures.

I hope this all makes sense, let me know if it doesn't and I'd love to see what you all achieve. If any of the meshes misbehave, let me know and I will try to upload corrections.

Monday, 20 May 2019

4 legs good, 2 legs better: How a dinosaur grows

The newest paper I've been involved in just came out, this time looking at Mussaurus and how it grows up (quick summary right at the end):


What is Mussaurus?
Mussaurus is a sauropodomorph. If that doesn't make things any clearer, it is an early relative of the long neck, long tailed dinosaurs we know as sauropods (things like Diplodocus, Apatosaurus, Brachiosaurus, etc.). Found in Argentina, it is now dated from the early Jurassic (about 200 million years ago), having previously been dated to the Triassic.
Simplified phylogeny/family tree of sauropodomoprhs modified from Otero et al., 2015 with all silhouettes from phylopic.org
The name Mussaurus translates as "mouse lizard", and comes from the fact the first individuals found were small hatchlings that fit in the palm of your hand. In the years since its description in 1979 there have been many more individuals found covering a range of ages and associated increase in size.

Ageing a dinosaur
Dinosaurs, like trees, have rings that can be counted to determine how old they are. These lines of arrested growth (LAGs) are found particularly in long bones. It gets a bit messy with many long bones having marrow cavities (like in humans) which as the animal gets larger, so too does the marrow cavity which starts obliterating the innermost LAGs. This means that the age estimates are often given as a minimum. For our study we worked with 3 ages of Mussaurus: the smallest being palm sized and based on the sizes of eggs found nearby presumed to be hatchlings; a bigger group with individuals being determined to be under a year (no LAGs), but likely close to that age; and the largest at least 8 years old, and possibly up to 10 (which will be the age in all of my graphs below).
Approximate sizes of the three different age groups from hatchling (bottom left), to yearling and adult.
Weighing a dinosaur
There are many ways to estimate the weight of a dinosaur but we chose 2 methods that are regularly  used in palaeontology. These are convex hulling and spline-based reconstruction:

Convex hull - this method works by building a simple geometric "box" (a hull) around bones, or series of bones to give a volume. All of the volumes are added together and multiplied by an estimated density for animals, and then multiplied by a correction factor. This correction factor is needed because the hulls are not biologically accurate (think of the amount of muscle usually on bones - see this earlier blog talking about it using lions). This method has been validated for calculating masses for mammals and birds.

Spline-based reconstructions - this method involves creating a series of hoops around various parts of the animal. For example, were the rib cage is, the hoop is built from the top of the vertebrae, around the ribs, and the gastralia/sternum. For the legs, different areas get hoops of different sizes as determined from the closest relatives of dinosaurs, birds and crocodiles (Allen et al., 2009). All of the hoops are ultimately joined together to create a 3D volume. The airways and lungs are also included. However there is variation between birds and crocodiles, and greater uncertainty with dinosaurs, so each of the segments (e.g. tail, chest, neck, arms, legs, airways/lungs) all get scaled up and down to create models with maximum and minimum estimates that are multiplied by the density of modern animals to get a mass. We can be fairly certain the real value lies somewhere between the extremes, but likely closer to the middle than the extremes.

Mass estimates between the two methods for Mussaurus.
The results between the 2 methods for masses are fairly similar. Hatchlings have a mass somewhere around 60-80g (about the size of a baby chicken/chick), by the time they are a year old they are 100x bigger at 8.19-8.30kg. That is an incredible amount of growth in a year. Just think about human babies being born around 3-4kg (6-8lbs) and being 300-400kg by the time they were 1 year old. For some of our domesticated birds this rate is exceeded, with modern turkeys carrying out this transition in size from 60g hatching to 8kg in 14-18 weeks (1/4 of the time) (Sogut et al,. 2016). In the next 7+ years of life for Mussaurus they continue growing at an incredible rate getting another 200x bigger reaching at least 1200-1500kg (about the size of a rhino or hippo). These growth rate are not unusual for dinosaurs, and the energetic requirements and stress associated with growing so much so quickly may be one of the major reasons there are so few "fully grown" adult dinosaurs of any species known with most dying before they attain their largest potential mass.

How can we use mass to infer posture?
Imagine you lean forward to touch your toes. Assuming you are flexible enough, this isn't too difficult. Now imagine having a really big head, or a long neck, or big arms and try again. You would likely find yourself tipping forwards. To counter this you might be able to bend your knees as if you were doing a squat and/or sticking your butt out to help keep yourself upright. However if your centre of mass gets too far forward, i.e. beyond your ability to get your foot (and by extension your knee) under your centre of mass, you will fall forward. This could be countered by reducing the mass of the front of your body (e.g. T. rex having tiny arms), having a big tail, or becoming quadrupedal (walking on all 4 limbs and using your arms to help support your mass). This simple biomechanical concept is what we applied to Mussaurus. The models allowed us to estimate the centre of mass for the different ages, and see how different regions influence the centre of mass.

We found that in the hatchlings the centre of mass is very far forward, about the length of the femur forward of the pelvis. This is the maximal theoretical limit of a centre of mass for a biped, assuming they held their femora horizontal when walking and only moved their lower legs. This of course is incredibly unlikely, and only seen in some real oddities today like penguins (who have of course become upright, and waddle), and also ignores the reality that you cannot put your knee perfectly forward of your hip as the stomach would get in the way (but you could move it to the side of your stomach, but this would have the effect of not being able to get your knee as far forward). As such we propose that Mussaurus hatchlings are quadrupedal. Through their growth the centre of mass moves back to a position that is very plausible for bipedal animals.
Centre of mass (COM) changes through ontogeny for Mussaurus. A COM of 1 would be directly between the shoulder blades, whilst a COM would be between the pelvis.
However, having a centre of mass that is closer to your hips does not instantly make you bipedal, but our data, combined with a previous study showing that the adult Mussaurus could not get its hands flat on the ground (Otero et al., 2017), strongly suggest it was bipedal. Therefore Mussaurus follows an human-like transition from being quadrupedal when young, but becoming bipedal when adults. This transition is associated with a relative reduction in head and neck size and a relative increase in tail size.

How does this fit in our understanding of sauropod evolution?
We know that the later sauropodomorphs, the sauropods, were quadrupedal. Their giant columnar limb bones in both their arms and legs are built to support their weight. Early sauropodomorphs are smaller with much less robust forelimbs and are likely bipedal. We know there is a transition from biped to quadruped somewhere in the group but does our study help? Many studies suggest that "ontogeny recapitulates phylogeny", i.e. where your evolutionary history is reflected in how you grow. If this was the case we would expect Mussaurus to show a bipedal to quadrupedal transition not the other way round. This shows that the evolutionary history of locomotion within the sauropodomorphs is far more complicated than it first appears.

Quick conclusion
The take home/TLDR: We used computer modelling to discover a very interesting growth sequence for Mussaurus, which not only grows at a rapid rate, but transitions from being quadrupedal to bipedal during it.

References

Allen V, Paxton H, Hutchinson JR, 2009. Variation in Center of Mass Estimates for Extant Sauropsids and its Importance for Reconstructing Inertial Properties of Extinct Archosaurs. Journal of Anatomy 292, 1442-1461.

Sogut BI, Celik SI, Ayasan TII, Inci H, 2016. Analyzing Growth Curves of Turkeys Reared in Different Breeding Systems (Intensive and Free Range) with some Nonlinear Models. Rev. Bras. Cienc. Avic. 18, 619-628.

Otero A, Allen V, Pol D, Hutchinson JR, 2017. Forelimb muscle and joint actions in Archosauria: insights from Crocodylus johnstoni (Pseudosuchia) and Mussaurus patagonicus (Sauropodomorpha). PeerJ 5:e3976.
